Tungsten Carbide Composite Welding Rods Hardfacing Rod for Oilfield Milling Shoe&Downhole Fishing Tools WC Overlay Welding Rod

No.1601586621961

Tungsten Carbide Composite Welding Rods are hardfacing welding consumables with tungsten carbide particles embedded in a metallic alloy matrix.

When welded on carbon steel or alloy steel surfaces, they build up a high-hardness anti-abrasion layer to resist sand, gravel and mineral abrasion.
Common applications: mining tools, drill bits, earthmoving blades, oil & gas wear parts, agricultural cutting tools.
Features: outstanding abrasive wear resistance, easy operation, good metallurgical bonding with base metal.

Download

View all downloads

Description

Key attributes

Model Number

ZZT21

Alloy Specification

YG8

Place of Origin

Hunan, China

Brand Name

ZZST

Particle

0.8~1.2um

Place of Origin

China

Hardness

HRA89.5-90

MOQ

5kgs

Package

Carton

Usage

Wear-resistance Parts

Color

Silver Gray

Dimensions

12*280,12*350, 16*450

Lead Time

7-15 Days

Keywords

sintered tungsten carbide composite welding rod or electrode

Application

Wear-resistant parts for Oil Well industry

Packaging and delivery

Selling Units

Single item

Single package size

50X30X30 cm

Single gross weight

5.000 kg

Tungsten Carbide Composite Welding Rods

Advantages:

1. High tungsten carbide granular content, outstanding abrasion resistance
2. Low dilution rate, maintains high hardness after overlay welding
3. Strong metallurgical bonding, hardfacing layer not easy to peel off
4. Stable welding performance, less spatter, easy operation
5. Resist impact & sand erosion, ideal for oilfield milling shoes /fishing tools
6. Uniform WC particle distribution, consistent service life
7. Wide application: oilfield downhole tools, drill bits, mining wear parts
8. Customizable rod diameter & WC particle size

Zhuzhou Jinzhou Tungsten Carbide Composite Welding Rod, also called Tungsten Carbide Welding Electrode, Carbide Brazing Rods or Carbide Welding Bars, is made of granular alloy and elastic matrix carbide. We have two options: Brass Copper Matrix Composite Rods and Nickle Matrix Composite rod. there is a special flux on the surface and colored in order to identify the granular size.

The main composition of sintering tungsten carbide scrap is mainly CO and WC, The hardness is about HRA 89~91, Matrix body is Ni or Brass Copper Alloy, strength can up to 690MPa, hardness HB≥160.

It is mainly used to overlay the worn-out and cutting usage workpieces in oil,mining,coal mining,geology,construction and other industries.Such as:milling shoes,wear shoes, junk mills, milling shoes, centralizers,reamer,drill pipe joints,hydraulic cutter,scraper blade plow planer,drill core, piling drill,auger,etc.

Grade Information

Grade	Grain Size	Density	Hardness	T.R.S
YG8	1~1.2 um	14.6~14.8g/cm3	≥89 HRA	2200~2800 MPa

Specifications and Sizes

Length of Rod (mm)	280/350/450/450
Diameter (mm)	12/12/16/22
Black Tungsten Carbide Grits Size (mm)	1.6-3.2
		3.2-4.8
		4.8-6.4
		6.4-8
		8-9.5
	9.5~12.7

A. Composite Rod with Brass Copper Matrix Alloy AWS: RBCuZn-A

WC Particle specifications			Binding Element Balance%
Content	Hardness	S221 Welding Wire	S221 Content Percent	S221 Melting Temperature
50~55%	89.5~91 HRA	45~50%	Cu：59~61% Sn：0.8-1.0, Si：0.15-0.35 Zn：balance	890-906°C
55~60%					40-45%
60~65%					35-40%
65~70%					30-35%
more than 70%					less than 30%

B. Composite Rod with Nickle Matrix Alloy AWS: RBCuZn-D

WC Particle specifications			Binding Element Balance %
Content	Hardness	S225 Welding Wire	S225 Content Percent	S225 Melting Temperature
50~55%	89.5~91HRA	45~50%	Cu：46~50% Si：0.04-0.25% Ni：9-11% Zn：balance	890-906°C
55~60%					40-45%
60~65%					35-40%
65~70%					30-35%
more than 70%					less than 30%

Q1: Are you a trading company or a manufacturer?
A1: We are a manufacturer. Our factory located in Zhuzhou City, Hunan, China. Welcome to visit our factory.

Q2: Can you provide free samples?
A2: For stocked items, we could provide few free samples for testing, but the extra shipping costs need to be charged, you can also use your own courier account if have. Samples will be sent to you by courier within 3 working days.
For no stock items, we have the MOQ requirement when ordering.

Q3: What is your MOQ?
A3: Different item has different MOQ, Pls consult with sales for the details.

Q4: What is terms of payment?
A4: Normally, When Payment value <=USD1000, we require 100% T/T prepaid before production. Otherwise, 50% T/T in advance, pay off the balance before shipping.

Q5: Do you offer OEM and ODM?
A5: Yes, we have rich experience in OEM and ODM. We can engrave logo and specifications on the products. In addition, we can also do custom printing on the packaging plastic box.

Q6: How to control the products quality?
A6: All products will be 100% tested before delivery, we will check the appearance, dimensions and performance to guarantee qualified products.

Q7:How to contact us?
A7: You can contact me by E-mail, Trademanager, Mobile, Whatsapp and so on.
